Mobility, versatility and best results – perfectly combined.

The new KAPEX KS 60 dispenses with everything not needed for the job – such as every unnecessary gram of weight. With impressive features such as ergonomically positioned carrying handles, cord holder and transport safety device and an extremely compact design thanks to flush-mounted guide rods, this device makes no compromises in terms of precision and versatility – with a mitre angle on both sides of up to 60 degrees and an inclination angle on both sides of up to 46 or 47 degrees. The Festool twin-column guide with two bearings ensures that the saw blade is guided reliably and smoothly. A range of other clever details such as the LED spotlight, the pull-out extension table, the additional groove function and the bevel help to make the KAPEX KS 60 a perfect combination of mobility, versatility and optimum results.



Compact and lightweight, with ergonomic handles and cord holder

LED spotlight to show cutting lines precisely (included in the set or available as an accessory)

Inclination angle of up to 47°/46° on each side and mitre angle of up to 60° on each side





Ideal for mobile use in assembly applications

Cutting boards and panels up to 305 x 60 mm

Trimming strips, profiles and square timber up to 60 mm thick

Precisely angled adjustment of skirting boards and cornices without calculations – in conjunction with the bevel





Power consumption 1 200 W

Idle engine speed 1 300 - 3 500 min⁻¹

Saw blade diameter 216.00 mm

Cutting depth 90°/90° 305 x 60 mm

Cutting depth at 45°/90° 215 x 60 mm

Cutting depth 45°/45° (left) 215 x 40 mm

Inclination angle 47/46 °

Mitre angle 60/60 °

Dimensions (W x D x H) 661 x 475 x 430 mm

Dust extraction connection diameter 27/36 mm

Cable length 3.70 m

Cutting depth 60°/90° 150 x 60 mm

Cutting depth 45°/45° (right) 215 x 20 mm

Product weight without accessories 17.90 kg

Transport weight incl. accessories 21.18 kg

Drive type Mains
